Ball Valve with Threaded Connection (DW-BV01)

Product Description

The Ball Valve with Threaded Connection is designed for efficient shut-off in liquid and gas systems. It features a stainless steel AISI316 body, providing durability and corrosion resistance. The threaded female connection ensures easy installation for various applications.

This valve operates with a lever handle and uses a quarter-turn mechanism for quick flow control. It supports a working pressure of 1.6 MPa and has been tested at 1.0 MPa by gas, ensuring reliability in demanding conditions. The pressure rating of PN63 and PN40 makes it suitable for high-pressure systems.

Manufacturers and suppliers in industrial, marine, and hydraulic sectors can benefit from this valve’s ISO 5211 compliance and optional NPT threading. It is available for bulk orders, aftermarket supply, and custom OEM solutions.

Technical Parameters

Features

• High Flow Capacity: Designed for liquid systems requiring efficient shut-off.

• Quarter-Turn Operation: Ensures quick and easy control.

• Full Bore Design: Allows unrestricted flow with minimal pressure drop.

• Three-Piece Bolted Body: Provides easy maintenance and servicing.

• Anti-Static Stem: Ensures operational safety in flammable applications.

• Top Flange ISO 5211: Compatible with various actuator mounting standards.

Advantages

• Durable Stainless Steel Body: Resistant to corrosion and harsh environments.

• Versatile Connection Type: Threaded female connection for easy installation.

• Wide Application Range: Suitable for corrosive fluids, oil, gas, and water.

• Customizable Options: NPT threading and other materials available on request.

• Reliable Pressure Handling: Rated for PN63 and PN40 for high-pressure applications.

Application

• Water Supply Systems: Used in pipelines for flow control.

• Oil and Gas Industry: Effective in fuel and lubricating oil systems.

• Marine and Offshore Use: Suitable for seawater and freshwater applications.

• Industrial Processing: Used in boiler feed water, condensate, and air systems.

• Hydraulic Systems: Compatible with flammable and non-flammable hydraulic fluids.

How to Maintain the Ball Valve

1. Regular Inspection:
   Check the valve regularly for any signs of wear, corrosion, or leakage, especially around the threads and stem.

2. Clean the Valve:
   Clean the valve periodically using a soft cloth to remove dirt, oil, and other residues. Ensure the valve body and threaded connections are free of debris.

3. Lubricate the Stem:
   Apply lubricant to the valve stem to maintain smooth operation, especially if the valve is used in corrosive environments.

4. Check Seals and Gaskets:
   Inspect the PTFE seals and gaskets for any damage or wear. Replace them if necessary to prevent leakage.

5. Operate the Valve:
   Perform the quarter-turn operation regularly to ensure the valve functions properly. This helps prevent seizing or jamming.

6. Avoid Over-Tightening:
   Do not over-tighten the threaded connection. This can cause damage to the threads and affect the sealing integrity.

7. Store Properly:
   If the valve is not in use for an extended period, store it in a dry, clean environment to prevent corrosion and damage.

FAQs

1. What is the pressure rating of this valve?

• The valve has a working pressure of 1.6 MPa and is tested at 1.0 MPa by gas, with a pressure rating of PN63 and PN40.

2. Can I customize the threading of the valve?

• Yes, the valve is available with NPT threading and other materials upon request.

3. What types of media can this valve handle?

• This valve is suitable for water, gas, oil, and other corrosive fluids, making it ideal for various applications.

4. How long does it take for delivery?

• Delivery time is typically 15-30 days, depending on the quantity of the order and our stock availability.

5. Do you provide OEM services?

• Yes, we offer OEM services for customized valves with specific branding and specifications.

6. How should I maintain the valve?

• Regular inspection and maintenance are recommended to ensure long-term performance. Ensure it is cleaned and checked for wear and tear.
